Dimension | 93*96*180mm | |
Bands | 5G NR ：n1/n3/n5/n7/n8/n20/n28/n38/n40/n41/n77/n78 LTE FDD : B1/B3/B5/B7/B8/B20/B28/B32 LTE TDD : B38/B40/B41/B42/B43 | |
Form factor | 5G/4G CPE | |
Wi-Fi | 802.11 b/g/n/ac/ax ; 2.4Ghz 2*2 MIMO 600Mbps; 5.8Ghz 2*2 MIMO 1200Mbps | |
Data Rates | NR sub6: DL 3.8Gbps/UL 2.5Gbps LTE：DL 1.6Gbps/UL 316Mbps 5G NR DL 4*4 MIMO; UL:2*2 MIMO ；LTE DL:4*4 MIMO | |
Hardware | RJ45 | 1* RJ45 auto WAN/LAN，1*RJ45 with 10/100/1000Mbps |
RJ11 | 1*RJ11 optional | |
SIM | 4FF, eSIM optional | |
LED | Power/Wi-Fi/4G/5G/Tel | |
Antenna | 5G/LTE- Internal antenna *4, Wi-Fi-Internal antenna *2 | |
Power | 12V/2A | |
Battery | Not Support | |
Button | Power，WPS | |
Software | Update | FOTA & Local update |
Support OS | Compatible with Windows / MACOS / Linux / Android | |
Others | IPv4/IPv6 | |
Operation Temperature | Operation Temperature:0 to 45℃ / Operation Humidity: 10% to 80% | |
Storage Temperature: -20 to 70℃ / Storage Humidity: 5% to 95% | ||
